Georg Neumann GmbH - Products/Current Microphones/TLM 102/Technical Data

Acoustical operating principle Pressure gradient transducer
Directional pattern Cardioid
Frequency range 20 Hz ... 20 kHz
Sensitivity at 1 kHz into 1 kohm 11 mV/Pa
Rated impedance 50 ohms
Rated load impedance 1 kohms
Equivalent noise level, CCIR1) 21 dB
Equivalent noise level, A-weighted1) 12 dB-A
Signal-to-noise ratio, CCIR1) (rel. 94 dB SPL) 73 dB
Signal-to-noise ratio, A-weighted1) (rel. 94 dB SPL) 82 dB
Maximum SPL for THD 0.5%2) 144 dB
Maximum output voltage 13 dBu
Dynamic range, A-weighted1) 132 dB
Supply voltage (P48, IEC 61938) 48 V ± 4 V
Current consumption (P48, IEC 61938) 3.5 mA
Matching connector XLR3F
